Owners manual

ADAPT | 7
Note 1: Always disconnect the negative battery terminal when working with any electrical circuits.
Note 2: When routing wires through any metal or abrasive surfaces, be sure the surface is free of any sharp edges.
1. Route harness through vehicle to desired termination points.
2. Match the light pigtail to the harness colors: Red to Red (+VDC main power), Black to Black (-VDC Ground), and
White to White (Data)
2a. Use provided wire connectors with appropriate wire gauge.
2b. Use a heat source to seal heat shrink tubing around wire and seal the connection.
LIGHT WIRING
LIGHT LEAD
HARNESS LEAD
BEFORE HEAT SHRINK AFTER HEAT SHRINK
