ADAPT | 11
UNDER DASH MODULE WIRING
CONNECTOR B – DASH CONTROLLER
The supplied Adapt dash controller is pre terminated by RIGID to plug directly into the Adapt Under Dash
Module. Ensure the dash controller cable is secured and does not have tension once installed.
CONNECTOR C – LIGHT BAR
The Adapt Harness is pre terminated by RIGID to plug directly into the Adapt Under dash module. Ensure the harness is
secured and does not have tension once installed.
CONNECTOR D – BLUETOOTH - COMING SOON
