UNDER DASH MODULE WIRING
Pin 1: Aux Switch Trigger - Backlighting LED
A. Use any auxiliary +12v input to trigger the backlighting LED’s without the use of the Adapt dash controller.
B. The Adapt system will store the previously defined backlighting color set by the Adapt dash switch. If the Adapt
dash controller is removed this feature can be used to trigger the backlighting LED’s with any OE/aftermarket switch.
C. To program this feature simply plug in the Adapt dash controller to the under dash module and select your desired
projecting mode and backlighting color. With the projecting mode and backlighting color activated remove the Adapt
dash controller and cycle the auxiliary switches on/off. Now the selected modes are saved and can be controlled by
the auxiliary switches. To change the setting plug the Adapt dash controller back into the under dash module and
change to the desired mode.
D. Once all connections are final, attach the battery leads to the vehicle’s battery.
Note: Both primary projecting mode and back lighting color must be in the on position before removing the Adapt Dash
controller in order for the auxiliary switches to function properly.
Note: The auxiliary switch trigger cannot change backlighting colors, it will only trigger the previously defined back
lighting color set by the Adapt dash controller
