KIT CONTENTS (1) Mounting Hardware (1) Mounting Brackets (2) Black Powder Coated L-Shape Brackets (1) Under Dash Module Harness (1) Dash Controller (1) Under Dash Module (1) Wiring Harness SOLD SEPARATELY Underside Low-Profile Stealth Mounts Light Covers GPS Module Magnetic GPS Antenna GPS ADAPT | 2
WIRING DIAGRAM LIGHT BAR LIGHT WIRING REFER TO PAGE 5 DASH CONTROLLER BT UNDER DASH MODULE Ignition *Required For Operation GPS Projecting LED Backlighting LED ADAPT | 3
BEAM PATTERNS Adapt offers 8 selectable beam patterns that range from broad short-distance lighting to highly focused long-distance lighting in a single fixture. It also includes RIGID’s new Active View Technology, which allows the beam pattern to actively adjust with vehicle speed. There are no moving parts within the Adapt. Instead, RIGID uses advanced LED technology and combines it with patented new optics to create a revolutionary lighting solution that can Adapt with changing conditions.
BEAM PATTERNS MODE 5 FLOOD DRIVING SPOT MODE 6 FLOOD DRIVING SPOT MODE 7 FLOOD DRIVING SPOT MODE 8 FLOOD DRIVING SPOT ADAPT | 5
MOUNTING A B C D E 1/4-20 x 1” Socket Head Bolt Black Powder Coated L-Shape Brackets Mounting Bushing End Cap 1/4-20 Nyloc Nut 1. Remove the (2) factory installed 1⁄4-20 x 1” Socket head bolts (A) from each side of light. 2. Install L-Bracket (B) mating against mount bushing (C) and re-install 1⁄4-20 x 1” Socket head bolts. 3. Mount light to desired mount location using customer supplied hardware. 4. Once light is aimed into position tighten fasteners (A) to 75in lbs.
LIGHT WIRING HARNESS LEAD LIGHT LEAD BEFORE HEAT SHRINK AFTER HEAT SHRINK Note 1: Always disconnect the negative battery terminal when working with any electrical circuits. Note 2: When routing wires through any metal or abrasive surfaces, be sure the surface is free of any sharp edges. 1. Route harness through vehicle to desired termination points. 2. Match the light pigtail to the harness colors: Red to Red (+VDC main power), Black to Black (-VDC Ground), and White to White (Data) 2a.
UNDER DASH MODULE WIRING A ACCESSORY PLUG 1 2 3 4 ACCESSORY A PIN WIRE COLOR DESCRIPTION 1 White Backlighting LED Trigger Projecting LED Trigger 2 Blue/White 3 Gray GPS 4 Red/White Ignition or Battery B DASH CONTROLLER 1 2 3 4 SWITCH B 2 3 LIGHTS 1 C PIN WIRE COLOR DESCRIPTION 1 Red 3.
UNDER DASH MODULE WIRING CONNECTOR A – ACCESSORY PLUG PIN 4: +VDC INPUT A. Input power for the under dash module to be wired to the factory ignition circuit or any +VDC trigger. Note: The input power will also trigger the backlighting on dash controller. If the under dash module is wired to constant +VDC the backlighting on the dash controller will always stay on. Pin 3: GPS A. Input for GPS Module (Sold Separately). This is required to activate the Adaptive mode.
UNDER DASH MODULE WIRING Pin 1: Aux Switch Trigger - Backlighting LED A. Use any auxiliary +12v input to trigger the backlighting LED’s without the use of the Adapt dash controller. B. The Adapt system will store the previously defined backlighting color set by the Adapt dash switch. If the Adapt dash controller is removed this feature can be used to trigger the backlighting LED’s with any OE/aftermarket switch. C.
UNDER DASH MODULE WIRING CONNECTOR B – DASH CONTROLLER The supplied Adapt dash controller is pre terminated by RIGID to plug directly into the Adapt Under Dash Module. Ensure the dash controller cable is secured and does not have tension once installed. CONNECTOR C – LIGHT BAR The Adapt Harness is pre terminated by RIGID to plug directly into the Adapt Under dash module. Ensure the harness is secured and does not have tension once installed.
DASH SWITCH OPERATION E. F. C. D. G. H. A. ADAPT | 12 B.
DASH SWITCH OPERATION A. POWER ACTIVATION Will activate the power to the primary projecting LED’s. B. ADAPTIVE MODE Will activate the Adaptive mode and vary the primary projecting beam pattern based on vehicle speed. B1. To program the Adaptive mode based on vehicle speed simply drive to desired vehicle speed for Mode 8 (full spot mode) and press the Adaptive mode button for 3 seconds or until the button flashes to save the setting. B2.
DASH SWITCH OPERATION F. RGB-W BACKLIGHTING CONTROL Activates the RGB-W backlighting and allows the end user to control the color desired. 1. To program the RGB-W backlighting first turn on the backlighting by activating the controller. Next, press and hold the RIGID button for 3 seconds or until the icon flashes. 2. Once in programming mode the backlighting will begin to color cycle and the RIGID font on the dash controller will mirror the color in the Adapt light bar. 3.
GPS MODULE WIRING DIAGRAM (SOLD SEPARATELY) 1 2 3 4 ACCESSORY GPS Antenna A 1 2 3 4 SWITCH B GPS Module 2 3 LIGHTS 1 C 1 2 BT 3 D ADAPT | 15
GPS MODULE OPERATION (SOLD SEPARATELY) This GPS module is required for the Adaptive Mode feature in the RIGID Adapt light bar. Once this unit is installed, the RIGID Adapt will use the GPS signal to automatically change modes based on vehicle speed. MOUNTING 1. Find the desired location to mount the GPS interface module that is protected against heat and water submersion. 2.
GPS MODULE OPERATION (SOLD SEPARATELY) 3. The Black Wire from the GPS module will share pin 3 connector C on the Adapt under dash module. This will provide chassis ground to the GPS unit. 4. The violet wire from the GPS module will go directly into pin 3 connector A on the Adapt under dash module. This will provide the GPS signal to the Adapt unit. OPERATION 1. Once the GPS unit is mounted and all wiring is connected properly, you are ready to test the unit. 2. Turn vehicle on.
NOTES ADAPT | 18
NOTES ADAPT | 19
WARRANTY INFORMATION For warranty information, visit www.rigidindustries.com/about/warranty 779 N Colorado St, Gilbert, AZ 85233 • 855-760-5337 www.rigidindustries.com Adapt, RIGID, and Rigid Industries are registered and/or common law marks owned by JST Performance, LLC, a Delaware limited liability company d/b/a Rigid Industries.
