Replacement Part List

999-995-015.10
Portable Power Drive
690-I
38
37
23
16
36
4
13
12
11
15
18
14
1
6
7
10
5
3
2
8
9
17
NOTE: Order parts by Catalog Number only.
DO NOT order by Reference Number.
RIDGID
®
4/14
Ref. Catalog
No.
No. Description
1 45663 Linecord 115V CE
45668 Linecord 115V CSA
45673 Linecord 220V CN
45678 Linecord 230V CE
45683 Linecord Swiss
2 45658 Strain Relief
3 45618 Capacitor 220V/230V/115V EU
4 45613 Slide Switch
5 45608 FOR/REV Switch
6 45633 Right Handle
7 45778 Red Brush Lead
8 45783 Black Brush Lead
9 45598 Brush Cap (2)
10 45593 Brush Assembly 115V (2)
45588 Brush Assembly 230V (2)
11 45583 Brush Holder (2)
12 45578 Motor Housing
13 45758 Red Field Lead
14 45763 Blue Field Lead
15 45768 Brown Field Lead
16 45773 Black Field Lead
17 45573 Field Mounting Screw (2)
18 45563 Field 115V
45568 Field 220V/230V
19 47108 Warning Decal
20 45623 ON/OFF Trigger
21 45603 Left Handle
22 45628 Screw (2)
23 45498 Screw (6)
24 45638 Screw (3)
25 45653 Screw (2)
26 45648 Cord Clamp
27 45558 Fan Shroud
28 45553 Bearing Sleeve
29 45548 Armature Bearing
30 45543 Dust Shroud
31 45528 Armature Pinion Bearing
32 45533 Armature Asm. 115V
45538 Armature Asm. 230V
33 47798 Gasket
34 45223 Spring Ring
35 45518 Spacer Bearing
36 45513 Bearing Washer
37 43232 FanHousing
38 45508 Washer(4)
26
24
22
23
25
21
19
20
35
34
28
29
30
31
32
33
27
Wiring Diagrams
115V
220/230V
