Specification

02/19 FORM NO. THD-PGPV N Rev. 5
PERFORMANCE
Power Vent
40, 50 and 75-Gallon Capacities
Up to 42,000 BTU/h
PERFORMANCE
®
Power Vent gas water heaters
offer up to 150 foot vent runs and the 50 and
40-Gallon Models are ENERGY STAR
®
approved
Efficiency
n .59 - .69 UEF
n ENERGY STAR
®
rated
Performance
n FHR: 66 - 110 gallons
n Recovery: Up to 42.4 GPH at a
90° F rise for 50 and 40-gallon
models, depending on model
Self-Diagnostic System
n Electronic diagnostic
gas control valve for
improved monitoring
and service
Low Emissions
n Eco-friendly burner, low NOx design
Features
n Uses indoor air for combustion;
blower exhausts the flue gases
n Standard 120 VAC electrical
connection
n New whisper quiet blower
Maintenance Free
Burner System
n Exclusive air/fuel shut-off device
n Maintenance free – no filter to clean
n Disables the heater in the presence of
flammable vapor accumulation
Flexible Venting Options
n Long venting lengths up to 150
equivalent feet
n PVC, ABS, or CPVC vent pipe
options
n Vertical or horizontal termination
Longer Life
n Patented anode rod design provides
long-lasting tank protection
Plus…
n Temperature and pressure relief valve
included
n Low lead compliant
n Durable Silicon Nitride Ignitor (HSI)
n Standard replacement parts
Warranty
n 6-Year limited warranty for tank
and parts, 1-year full in-home labor
warranty*
*See written warranty for complete details
Units meet or exceed ANSI requirements and have
been tested according to D.O.E. procedures. Units
meet or exceed the energy efficiency requirements
of NAECA, ASHRAE standard 90, ICC Code and all
state energy efficiency performance criteria.
Maintenance Free
Flame Arrestor PlateCombustion Shut-off System
LEED Point = 1
See specifications chart on back.
®
