SALES FACT SHEET
RHML SERIES
Models with Efficiencies
up to 16 SEER / 13 EER
GENERAL TERMS OF LIMITED WARRANTY*
Rheem will furnish a replacement for any part of this product which fails in
normal use and service within the applicable period stated, in accordance with
the terms of the limited warranty.
Conditional Parts (Registration Required)................. Ten (10) Years
*See Product Warranty Card for Details
Air Handler
Features
■
RHML feature GE’s new X-13 (ECM) motor which provides enhanced SEER
performance with most Rheem outdoor units.
■
2 ton [7.0 kW] through 5 ton [17.6 kW] models are between 42
1
/2 to 55
1
/2
inches [1080 to 1410 mm] tall and 22 inches [559 mm] deep.
■
Versatile 4-way convertible design for upflow, downflow, horizontal left and
horizontal right applications.
■
Factory-installed high efficiency indoor coil.
■
All models meet or exceed 330 to 400 CFM [156 to 189 L/s] per ton at .3
inches [.7 kPa] of external static pressure.
■
Enhanced airflow up to .7" external static pressure.
■
Sturdy construction with 1.0 inch [.24 kPa] of reinforced foil faced jacket
insulation for excellent thermal and sound insulation.
■
Field-installed auxiliary electric heater kits provide exact heat for indoor
comfort. Kits include circuit breakers which meet UL and cUL requirements
for service disconnect.
MODEL
RHML
ELECTRIC HEAT
RANGE
NOMINAL
SIZE
PHASE
HEIGHT
WIDTH
LENGTH
SHIPPING
WEIGHT
MINIMUM
CIRCUIT
AMPACITY
PRICE
HM2421JA
HM3621JA
HM4824JA
HM6024JA
24,000
30,000
36,000
42,000
24,000
36,000
48,000
60,000
1
1
1
1
42 - 1/2"
50 - 1/2"
55 - 1/2"
55 - 1/2"
21"
21"
24 - 1/2"
24 - 1/2"
21 - 11/16"
21 - 11/16"
21 - 11/16"
21 - 11/16"
2
5
6
6
97/112
150/166
181/198
181/198
“Proper sizing and installation of equipment is critical to achieve optimal performance.
Ask your Contractor for details or visit www.energystar.gov.”
