Submittal Sheet

DOWNFLOW MODELS
HORIZONTAL MODELS
MODEL
RGTM-
A B C D E F
LEFT
SIDE
MINIMUM CLEARANCE (IN.) [mm]
SHIP
WGTS.
[kg]
RIGHT
SIDE
BACK TOP FRONT VENT
06
17
1
/2 [445] 16
11
/32 [415] 15
5
/8 [397]
2 [51]
16
5
/8 [422] 13
7
/8 [352]
0 0 0 1 [25] 2 [51] 0 123 [56]
07 21 [533] 19
27
/32 [504] 19
3
/16 [486] 2 [51] 20
1
/8 [511] 17
3
/8 [441] 0 0 0 1 [25] 2 [51] 0 123 [56]
09 21 [533] 19
27
/32 [504] 19
3
/16 [486] 2 [51] 20
1
/8 [511] 17
3
/8 [441] 0 0 0 1 [25] 2 [51] 0 148 [67]
10 24
1
/2 [621] 23
11
/32 [593] 22
5
/8 [575] 2 [51] 23
5
/8 [600] 20
7
/8 [530] 0 0 0 1 [25] 2 [51] 0 165 [75]
IMPORTANT NOTE: Horizontal furnace may be installed for horizontal left hand air supply ONLY. The condensate trap provided for horizontal application
must be installed in the field beneath the unit as directed in the furnace Installation & Operating Instructions.
Before proceeding with installation, refer
to installation instructions packaged
with each model, as well as complying
with all Federal, State, Provincial, and
Local codes, regulations, and practices.
Rheem Sales Company, Inc.
P.O. Box 17010, Fort Smith, AR 72917
“In keeping with its policy of continuous progress and product improvement, Manufacturer reserves the right to make changes without notice.”
PRINTED IN U.S.A. 7-12 QG FORM NO. X33-1370
Supersedes Form No. X33-1296
[ ] Designates Metric Conversions
