Rheem Manufacturing Company 5
1
1
/2
[41 mm]
20
5
/16
[516 mm]
7
11
/16
[196 mm]
A
Accessories (cont.)
• UNCASED COIL ADAPTER KIT
RXBA- (See Figure 3 & 4)
This uncased coil adapter kit is used to adapt the coil to a furnace
or ductwork. See Table 6 to order the proper adapter kit. Each kit
contains a quantity of 20 adapters.
FIGURE 3: UNCASED COIL ADAPTER KIT ILLUSTRATION
FIGURE 4: UNCASED COIL ADAPTER KIT ASSEMBLED
Note: Sliding the coil into the coil rail before attaching coil rack front.
B14x20 13
1
/
8
[333]
B17x20 16
5
/
8
[422]
Uncased Coil Adapter
Model Number RXBA
A
Width (in.) [mm]
B21x20 20
1
/
8
[511]
-HUxx14
-HUxx17
Uncased Coil
Model RCFA/L
-HUxx21
B24x20 23
5
/
8
[599]
-HUxx24
[ ] Designates Metric Conversions
Table 6: Uncased Coil Adapter Kit
