FORM NO. C11-211 REV. 2

Supersedes Form No. C11-211 Rev. 1

INDOOR COILS

CASED/UNCASED COILS

FOR GAS AND

OIL FURNACES

AIRFLOW CAPACITIES

600-1,900 CFM

[283-897 L/s]

Rheem

Indoor Coils are designed for use with Rheem out-

door units and are available for vertical upflow or downflow,

and horizontal left or horizontal right airflow. When matched

with Rheem outdoor units, the coils provide a nominal

capacity range from 18,000 BTU/HR [5.24 kW] to 60,000

BTU/HR [17.58 kW].

■ Constructed of aluminum fins bonded to internally

grooved copper tubing.

■ Coils are tested at the factory with an extensive refriger-

ant leak check.

■ Coils have sweat refrigerant connections.

■ Ideally suited for new installations or add on air

conditioning.

■ Feature two sets of

/4" [14.1 mm] N.P.T. Condensate

drain connections for ease of connection.

■ Coils are A.R.I. certified for system application with variety

of Rheem outdoor units.

■ Condensate drain pan is constructed of high grade, heat

resistant, corrosion free thermal-set material.

■ Compatible with Germicidal Light System (UV resistant)

■ Bi-Directional airflow eliminates the need to switch any

internal components from horizontal left to right.

■ Unique drain pan design maximizes application flexibility

and condensate removal.

RCFA- featuring

R-22 Refrigerant

RCFL- featuring

Earth-Friendly

R-410A Refrigerant

earth friendly refrigerant

Summary of content (8 pages)

PAGE 1
FORM NO. C11-211 REV. 2 Supersedes Form No. C11-211 Rev. 1 INDOOR COILS RCFA- featuring R-22 Refrigerant RCFL- featuring Earth-Friendly R-410A Refrigerant earth friendly refrigerant CASED/UNCASED COILS FOR GAS AND OIL FURNACES AIRFLOW CAPACITIES 600-1,900 CFM [283-897 L/s] Rheem® Indoor Coils are designed for use with Rheem outdoor units and are available for vertical upflow or downflow, and horizontal left or horizontal right airflow.
PAGE 2
MODEL NUMBER DATA R C F A — HM 24 14 A C Gas/Oil Furnace Coil C = Cased U = Uncased Design Variation A = 1st Design Coil Size 14 = 14" [356 mm] 17 = 17.5" [431.8 mm] 21 = 21" [533.4 mm] 24 = 24.5" [609.6 mm] Nominal Capacity 24 = 18,000 to 24,000 BTU/HR [5.27 to 7.03 kW] 36 = 30,000 to 36,000 BTU/HR [8.79 to 10.55 kW] 48 = 42,000 to 48,000 BTU/HR [12.31 to 14.06 kW] 60 = 60,000 BTU/HR [17.
PAGE 3
Table 2: Coil Dimensions and Weights Coil Model RCFA/RCFL Connections Sweat (in.) [mm] Cased Coil Dimensions (in) [mm] Liquid Suction I.D. I.D. Weight A B C Coil Weight (lbs.) [Kg.] Shipping Weight (lbs.) [Kg.] 2414* 3/8 [9.53] 3/4 [19.05] 14 1/2[356] 21 1/2[533] 233/16 [584] 46 [21] 50 [23] 2417 3/8 [9.53] 3/4 [19.05] 171/2 [445] 141/2 [368] 20 1/2 [508] 46 [21] 51 [23] 3617 3/8 [9.53] 3/4 [19.05] 171/2 [445] 177/8 [454] 20 1/2 [508] 52 [24] 57 [26] 3621 3/8 [9.
PAGE 4
Table 3: Coil Application Coils can be matched to heating products as listed in table below. Furnace Width (In.) (mm) Coil Model RCFA/RCFL Oil 2414 2417 3617 Gas — 14 2417 3617 21 [533] 3621 4821 21 [533] 4824 6024 241/2 [622] [356] 171/2 [444] 14 [356] 21 [533] 171/2 [444] 241/2 [622] 21 [533] *Note: Due to the proximity of the drain pan to the high temperature oil furnace drain, horizontal left application is not permitted on all oil furnaces.
PAGE 5
Accessories (cont.) • UNCASED COIL ADAPTER KIT RXBA- (See Figure 3 & 4) This uncased coil adapter kit is used to adapt the coil to a furnace or ductwork. See Table 6 to order the proper adapter kit. Each kit contains a quantity of 20 adapters. FIGURE 3: UNCASED COIL ADAPTER KIT ILLUSTRATION 11/2 [41 mm] Table 6: Uncased Coil Adapter Kit Uncased Coil Adapter Model Number RXBA A Width (in.
PAGE 6
NOTES 6 Rheem Manufacturing Company
PAGE 7
NOTES Rheem Manufacturing Company 7
PAGE 8
Before proceeding with installation, refer to installation instructions packaged with each model, as well as complying with all Federal, State, Provincial, and Local codes, regulations, and practices. RHEEM AIR CONDITIONING DIVISION 5600 Old Greenwood Road, Fort Smith, Arkansas 72908 “In keeping with its policy of continuous progress and product improvement, Rheem reserves the right to make changes without notice.” PRINTED IN U.S.A. 11-06 DC FORM NO. C11-211 REV. 2 Supersedes Form No. C11-211 Rev.
