ABOUT YOUR WATER HEATER
8
PRECAUTIONS
Where damage to property can occur in the event of the water heater leaking, the water heater must be
installed in a safe tray. Construction, installation and draining of a safe tray must comply with AS/NZS 3500.4
and all local codes and regulatory authority requirements.
The water heater must be maintained in accordance with the Owner‟s Guide and Installation Instructions.
Refer to “Regular Care” on page 13 and to “Anode Inspection and Replacement” on page 17.
If this water heater is to be used where an uninterrupted hot water supply is necessary for your application or
business you should ensure that you have back up redundancy within the hot water system design. This
should ensure the continuity of hot water supply in the event that this water heater were to become
inoperable for any reason. We recommend you seek advice from your plumber or specifier about your needs
and building back up redundancy into your hot water supply system.
PIPE WORK AND INSULATION
The solar hot and solar cold pipe work between the solar storage tank and the solar collector(s) and between
the solar storage tank and a remote in-series water heater (if one is installed) MUST BE of copper.
The full length of the solar hot and solar cold pipes MUST BE insulated. The insulation must:
be of a closed cell type or equivalent, suitable for a solar water heating application and capable of
withstanding the temperature of the water generated by the solar collectors under stagnation conditions
be at least 13 mm thick, however thicker insulation may be required to comply with the requirements of
AS/NZS 3500.4
be weatherproof and UV resistant if exposed
extend through any penetrations in the eaves, ceiling and roof
cover valves and fittings in the solar hot and solar cold pipe work
be fitted up to and cover the connections on both the solar storage tank and the solar collectors.
Note: Failure of these requirements to be observed increases the risk of freeze damage.
Uninsulated pipe work, including concealed in cavities and roof spaces or where it may be in contact with a
metal roof, may lead to freeze damage. There is NO WARRANTY for freeze damage if the solar hot and
solar cold pipes are not insulated in accordance with the installation instructions.
Note: Any exposed pipe work or fittings in the solar circuit should be attended to and covered with insulation.
Phone Rheem Service or their nearest Accredited Service Agent to arrange for an inspection.
The insulation is essential to assist in providing freeze protection, will offer corrosion protection to a metal
roof against water runoff over the copper pipe, assist in avoiding accidental contact with the solar pipe work
as high temperature water can flow from the solar collectors to the solar storage tank and also reduce pipe
heat losses.
Plastic pipe MUST NOT be used, as it will not withstand the temperature and pressure of the water
generated by the solar collectors under certain conditions (refer to Warning on page 40).
