INSTALLATION – SOLAR COLLECTOR(S)
38
The risks include:
the collector glass not 'self cleaning', leading to dirty collector glass reducing solar performance,
condensation on the underside of the glass taking longer to clear,
condensation droplets falling onto the absorber plate potentially causing discolouration.
The collector kit is suitable for installations with an inclination of up to 45°.
A Variable Pitch frame can be installed to increase the angle of inclination of the collector used in a pumped
solar direct water heater installation. This type of frame should be used if the roof pitch either varies by more
than 20° from the optimum angle or if the roof pitch is less than 10°.
Alternatively a Fixed Low-Pitch frame, for a single TBT260 solar collector installation, may be used where
this meets local regulatory requirements. Refer to your local Solar Distributor for details.
The use of a Variable Pitch or Fixed Low-Pitch frame should be discussed with the system owner. If this
option is neither possible nor acceptable to the system owner, then the system owner needs to be made
aware of, understand and accept that increased boosting may be required to meet their hot water
requirements.
The installation of the solar collector(s) on a suitable frame, subject to the frame‟s design criteria not being
exceeded is suitable for installation in geographic locations up to and within Wind Region B (Variable Pitch or
Fixed Low-Pitch frame), as defined in the Building Code of Australia, Australian / New Zealand Standard
AS/NZS 1170.2:2002 and the Australian Standard AS 4055-2006, or equivalent location.
LATITUDE OF SOME AUSTRALIAN CITIES
Adelaide
35°S
Cairns
17°S
Hobart
42°S
Port Hedland
20°S
Alice Springs
24°S
Canberra
35°S
Mildura
34°S
Rockhampton
24°S
Brisbane
27°S
Darwin
12°S
Melbourne
38°S
Sydney
34°S
Broken Hill
31°S
Geraldton
28°S
Perth
32°S
Townsville
19°S
MAXIMUM NUMBER OF COLLECTORS
The maximum number of solar collectors which may be installed is:
Tank Model
HPT200 *
selective surface
TBT260
selective surface
511160
2 *
1
* Victoria only if installed greater than 60° off solar north.
