Submittal Sheet

Before proceeding with installation, refer
to installation instructions packaged
with each model, as well as complying
with all Federal, State, Provincial, and
Local codes, regulations, and practices.
Rheem Sales Company, Inc.
P.O. Box 17010, Fort Smith, AR 72917
“In keeping with its policy of continuous progress and product improvement, Rheem reserves the right to make changes without notice.”
PRINTED IN U.S.A. 10-08 DC FORM NO. X33-1270
Supersedes Form No. X33-1260
ELECTRICAL CONNECTIONS
MAY EXIT TOP OR EITHER SIDE
HIGH VOLTAGE CONNECTION
7
/8 [22.2 mm],
1
3
/32 [27.8 mm], 1
31
/32 [50 mm]
DIA. KNOCKOUT
LOW VOLTAGE CONNECTION
5
/8 [15.9 mm] AND
7
/8 [22.2 mm] KNOCKOUT
VAPOR LINE CONNECTION
COPPER (SWEAT)
DOWNFLOW APPLICATION AND HORIZONTAL RIGHT
INDOOR COIL AND COIL DOOR ROTATES 180°
PRIMARY DRAIN CONNECTION
3
/4 [19.1 mm] FEMALE PIPE THREAD (NPT)
AUXILIARY DRAIN CONNECTION
3
/4 [19.1 mm] FEMALE PIPE THREAD (NPT)
UPFLOW/DOWNFLOW APPLICATION ONLY
LIQUID LINE CONNECTION
COPPER (SWEAT)
AUXILIARY DRAIN CONNECTION
3
/4 [19.1 mm] FEMALE PIPE THREAD (NPT)
HORIZONTAL APPLICATION ONLY
NOTE: 24 CLEARANCE REQUIRED IN FRONT OF
UNIT FOR FILTER AND COIL MAINTENANCE.
A
W
H
19
1
/2 [495 mm]
RETURN AIR
OPENING
21
11
/16
[551 mm]
10
5
/16
[262 mm]
SUPPLY AIR
Unit Dimensions
Return Air Opening Dimensions
Model
Cabinet Size
Return Air
Opening Width
(Inches)
Return Air Opening
Depth/Length
(Inches)
21
19
3
/8 19
1
/2
24
22
7
/8 19
1
/2
RHPN-
Supply
Duct
“A” In. [mm]
Nominal Coil Airflow [L/s]
Unit Weight/Shipping
Weight (Lbs.) [kg]
Unit With
Coil (Max. KW)
ODD* ODD*
2421 19
1
/2 [495] 500 [238] 860 [307] 92/106
Unit
Width
“W” In. [mm]
21
1
/2 [533]
Unit
Height
“H” In. [mm]
42
1
/2 [1080]
Normal
600 [283]
Normal
775 [366]
1st Stage 2nd Stage
3624 24
1
/2 [622] 55
1
/2 [1410] 23
1
/2 [584]
725 [342] 825 [389] 975 [460] 1175 [555]
181/198
825 [389] 950 [448] 1000 [472] 1175 [555]
4824
24
1
/2 [622] 55
1
/2 [1410] 23
1
/2 [584]
825 [389] 1000 [472] 1300 [614] 1600 [755]
181/198
1000 [472] 1200 [566] 1350 [637] 1600 [755]
6024
24
1
/2 [622] 55
1
/2 [1410] 23
1
/2 [584]
925 [437] 1050 [496] 1325 [625] 1700 [802]
181/198
1025 [484] 1275 [602] 1400 [661] 1700 [802]
[82]/[90]
[42]/[48]
[82]/[90]
[82]/[90]
Matched to
Outdoor Unit
(-)ASL-036JEC
(-)ARL/(-)ASL-036JEC
(-)ASL-048JEC
(-)ARL/(-)ASL-024JEC
(-)ARL-048JEC
(-)ASL-060JEC
(-)ARL-060JEC
[ ] Designates Metric Conversions
( ) Designates Unit with Double Coil Cabinet
HORIZONTAL ADAPTER KIT
VAPOR LINE
CONNECTION
AUXILIARY HORIZONTAL
DRAIN CONNECTION
PRIMARY DRAIN
CONNECTION
AUXILIARY UPFLOW/DOWNFLOW
DRAIN CONNECTION
LIQUID LINE
CONNECTION
VERTICAL DRAIN PAN
5
15
/16
[151 mm]
4
1
/8
[105 mm]
3
1
/16
[76 mm]
1
3
/16 [48 mm]
1
1
/8 [29 mm]
1
1
/16
[27 mm]
1
3
/8
[35 mm]
2
13
/16
[71 mm]
5
1
/4
[133 mm]
5
3
/8
[136 mm]
UPFLOW UNIT SHOWN:
UNIT MAY BE INSTALLED UPFLOW,
DOWNFLOW, HORIZONTAL RIGHT
OR LEFT AIR SUPPLY.
*Maximum dehumidification airflow. Refer to interface board section for more information. [ ] Designates Metric Conversions
Unit Dimensions & Weights
