COMMAND LINE INTERFACE
Command Summary
350-7951 Quadra User’s Guide 74
. . . . .
MISCELLANEOUS
. . . . . . . . .
COMMANDS
The Miscellaneous commands category control includes a variety of general
Quadra functions. A summary of commands is listed below. Click the desired
command to access detailed instructions.
Refer to the “Miscellaneous Commands Descriptions
” section for a complete
description of all miscellaneous Quadra commands.
Table 4-14.
Miscellaneous Commands Summary
Command Description
BackGroundSouRCe Selects a colored or shaded background that appears behind an output
channel.
Help Displays the entire serial command set or provides help on specific
commands.
ID
Displays system information including firmware version numbers.
RestoreFactoryDefaults
Restores all user settings to their factory default values.
RECALLCONFIGuration
Recalls configuration parameters that were saved manually.
SAVECONFIGguration Manual save of the system’s NVRAM.
SETTINGSEXPORT
Exports an ASCII file of system settings to the terminal or controller.
SETTINGSIMPORT
Accepts ASCII data relating to system settings.
STATus Returns the status of the Quadra and its current settings.
SYStemReSeT
Resets the Quadra system (software reset).
TestPattern Turns on the designated Test Pattern.
UpdateFirmWare Updates the firmware for the Quadra.
VERsion
Returns firmware, hardware and bootcode revision information.
