OUTPUT
. . . . . . . . .
COMMANDS
Output commands control Quadra’s output channels. They define the output
timing and sync format, and save, load, and delete timings to the Output List. A
summary of output commands is listed below. Click the desired command to
access detailed instructions.
Refer to the “Output Commands Descriptions
” section for a complete
description of all output commands.
Table 4-4.
Output Commands Summary
Command Description
OutPutENable Switch or fade the output to or from black.
OutPutREFerence Selects the output’s timing reference.
OutPutTiMing
For the selected output channel, sets the output timing by parameter.
OutPutTiMing INTeractive
Enters the interactive output timing adjustment mode for the selected
output channel.
OutPutTiMingLOAD For the selected output channel, sets output display parameters from
values stored in Factory Timing List.
OutPutTiMingNAME
For the selected output channel, assigns a user-defined name to the
Factory Timing List entry in use.
OutPutTiMingSAVE
For the selected output channel, saves the current output timing settings
to the specified user timing slot.
