Quadra User's Guide

COMMAND LINE INTERFACE
Command Format
350-7951 Quadra User’s Guide 54
. . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
To execute commands, each command line must be followed by a
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
carriage return (pressing Enter).
. . . . . . . . .
COMMAND HELP
S Commands: “Help”
There are two primary ways to use the Quadra’s help feature:
• Type HELP to list all Quadra commands.
• Type HELP followed by the command to get command-specific help.
S Example: Type H BRI to get help on the Brightness
function.
S Example: Type H WSR to get help on the Window Source
Rectangle function.
PREDEFINED
PARAMETER
. . . . . . . . .
VALUES
Some commands have predefined values, and only these may be used as
parameter choices. Predefined parameter choices are indicated as
<value1|value2|value3>
S Example: The choices for BAUDrate are:
<9600 | 19200 | 38400 | 57600 | 115200>
QUERY THE
. . . . . . . . .
CURRENT SETTING
When a command is entered without any parameters, Quadra reports back the
current settings of the selected parameter.
S Example: What is the current baud rate setting ?:
BAUDrate
would return:
9600
PARAMETER
. . . . . . . . .
RANGES
Parameter values may be a “range” of values, or a defined set of choices (as
described above in the “Predefined Parameter Values
” section).
Ranges are indicated as:
<value1 ... value2>
S Example: The value of BRIght is a range of
<-500 ... 500>
ADDRESSABLE
. . . . . . . . .
COMMANDS
Commands such as BAUDrate do not need an explicit address, as Quadra has
only a single serial port. However, other commands can be applied to several
destinations. For example the “brightness” command can apply to all Quadra
inputs or to an individual input — depending upon how the command sequence
is structured.
