~ Input #3 is cropped to the exact lower left quadrant of the
source image.
~ Input #4 is cropped to the exact lower right quadrant of the
source image.
The net result on your 2x2 monitor wall is a perfectly expanded source
image.
8. To switch back to full size inputs on each output channel, use the
UDC
command. Type:
UDC Enter
