Technical data

6
80
Manual – Gear Units and Gearmotors
Input shaft assembly AD (→ GK)
Project Planning for Components on the Input Side
Selecting the
gear unit
Determine the gear unit type
↓
Determine the gear unit size by means of the
• Maximum output torque (T
a max
)
• Gear ratio (i)
in the gear unit selection tables with input shaft assembly AD
When selecting AD/P, please observe the selection note on page 82.
↓
Check the maximum permitted overhung load value on the output (F
Ra
).
↓
Check the maximum permitted input power at the gear unit (P
e
) by taking account of
the thermal limit rating (see page 83).
↓
Check the overhung load at the input (F
Re
).
↓
In the case of other requirements (such as higher overhung loads on the input side),
please contact SEW-EURODRIVE.
