Technical data

6
72
Manual – Gear Units and Gearmotors
Adapter with hydraulic centrifugal coupling AT (→ GK)
Project Planning for Components on the Input Side
Characteristic
curves
Selecting the
gear unit
Motor startup Driven machine startup Torque /time characteristic
Motor speed Machine speed Time
T
T
T
T
T
T
T/T
T/T
T/T
K
K
L
K
M
M
N
N
N
20 sec.
1
1
1
0
0
0
2
2
2
5 sec.
T
M
Motor torque
T
L
Load torque
T
K
Coupling torque
T
N
Fusible safety plug
Determine the gear unit type
↓
Determine the gear unit size by means of the
• Maximum output torque (T
a max
)
• Gear ratio (i)
in the gear unit selection tables with adapter AM
↓
Determine the adapter type by means of the
• Motor speed (n
M
)
• Gear unit size
• Rated power of the driving motor (P
m
)
in the selection tables for adapter AT
