Manual – Gear Units and Gearmotors
Adapter AQ for servomotors (→ GK)
Project Planning for Components on the Input Side
Selecting the
gear unit
Determine the gear unit type
↓
Determine the gear unit size by means of the
• Maximum output torque (T
a max
)
• Gear ratio (i)
in the selection tables AQ
↓
Check the maximum permitted overhung load value on the output (F
Ra
)
↓
Check the permitted input torques on the gear unit (T
e max
)
(see “Power ratings, mass moments of intertia" on the previous page)
↓
Is the required adapter size available?
↓
Is the required combination feasible?
