Adapter AQ for servomotors (→ GK)
Project Planning for Components on the Input Side
Torques, mass
moments of
inertia
Required motor
data
As the dimensions of servomotors are not standardized, the following motor data must
be known to select the appropriate adapter:
• Shaft diameter and length
• Flange dimensions (edge length, diameter, centering shoulder and hole circle)
• Maximum torque
Do not hesitate to contact us if you have questions on selection and project planning.
Type d
RZ
1)
[mm]
1) The pinion diameter depends on the gear ratio, please contact SEW-EURODRIVE.
T
e max
2)
[lb-in]
2) Maximum permitted input torque (applies to ambient temperatures of -22 °F to +140 °F; with AQH → di-
ameter tolerance of the motor shaft k6)
J
adapter
3)
[lb-ft
2
]
3) Mass moment of inertia of the adapter to be driven
AQ..80/..
10 68
21.375 • 10
-4
12 115
AQ..100/..
AQ..115/1
AQ..115/2
10 68
38.10
-4
12 115
14 133
16 133
AQ..115/3
10 68
87.875 • 10
-4
12 115
14 168
16 265
AQ..140/1
AQ..140/2
16 265
133.10
-4
18 365
22 470
AQ..140/3
16 265
268.375 • 10
-4
18 365
22 665
AQ..190/1
AQ..190/2
22 665
387.125 • 10
-4
28 1280
AQ..190/3
22 665
688.75 • 10
-4
28 1500
