Manual – Gear Units and Gearmotors
Gear units with IEC or NEMA adapter AM (→ GK)
Project Planning for Components on the Input Side
Power ratings,
mass moments of
inertia
Selecting the
gear unit
Check the input
power at the gear
unit (P
n
)
The values in the selection tables refer to an input speed of n
e
= 1750 rpm. The input
power at the gear unit corresponds to a maximum torque at the input side. If the speed
deviates, convert the input power by means of the maximum torque.
Type (IEC) Type (NEMA) P
m
1)
[HP]
1) Maximum rated power of the attached standard electric motor at 1750 rpm (applies to ambient
temperatures of -22 °F to +140 °F)
J
adapter
[lb-ft²]
AM63 - 0.33 10.45 • 10
-4
AM71 AM56 0.50 10.45 • 10
-4
AM80 AM143 1.0 45.125 • 10
-4
AM90 AM145 2.0 45.125 • 10
-4
AM100 AM182 4 123.5 • 10
-4
AM112 AM184 5.4 123.5 • 10
-4
AM132S/M AM213/215 10 451.25 • 10
-4
AM132ML - 12.5 451.25 • 10
-4
AM160 AM254/256 20 2161.25 • 10
-4
AM180 AM284/286 30 2137.5 • 10
-4
AM200 AM324/326 40 4132.5 • 10
-4
AM225 AM364/365 60 4132.5 • 10
-4
AM250 - 75 4108.75 • 10
-4
AM280 - 120 16268.75 • 10
-4
Determine the gear unit type
↓
Determine the gear unit size by means of the
• maximum output torque (T
a max
)
• Gear ratio (i)
in the gear unit selection tables with adapter AM
↓
Check the maximum permitted overhung load value on the output (F
Ra
)
↓
Check the maximum permitted input power at the adapter (P
m
)
(see “Power ratings, mass moments of intertia” on page 60)
↓
Is the required adapter size available?
↓
Is the required combination feasible?
