Manual – Gear Units and Gearmotors
35
3
Gearmotor types
Unit Designations and Versions
03174AXX
KHF..DR/DT/DV..
Helical-bevel gearmotor in B5 flange-mounted version with
hollow shaft and shrink disc
KA..DR/DT/DV..
Helical-bevel gearmotor with hollow shaft
KV..DR/DT/DV..
Helical-bevel gearmotor with hollow shaft and splined
hollow shaft to DIN 5480
KH..DR/DT/DV..
Helical-bevel gearmotor with hollow shaft and shrink disc
KT..DR/DT/DV..
Helical-bevel gearmotor with hollow shaft and TorqLOC
®
hollow shaft mounting system
KAZ..DR/DT/DV..
Helical-bevel gearmotor in B14 flange-mounted version
with hollow shaft
KVZ..DR/DT/DV..
Helical-bevel gearmotor in B14 flange-mounted version
with hollow shaft and splined hollow shaft to DIN 5480
KHZ..DR/DT/DV..
Helical-bevel gearmotor in B14 flange-mounted version
with hollow shaft and shrink disc
