Gearmotor types

Unit Designations and Versions

3.11 Gearmotor types

Helical

gearmotors

The following types of helical gearmotors can be supplied:

The types described in this section refer to gearmotors from SEW-EURODRIVE. They

also apply to gear units without motor (without DR/DT/DV) and for MOVIMOT

gear-

motors (../MM..).

59848AXX

RX..DR/DT/DV..

Single-stage foot-mounted helical gearmotor

RXF..DR/DT/DV..

Single-stage B5 flange-mounted helical gearmotor

R..DR/DT/DV..

Foot-mounted helical gearmotor

R..F DR/DT/DV..

Foot and B5 flange-mounted helical gearmotor

RF..DR/DT/DV..

Helical gearmotor in B5 flange-mounted version

RZ..DR/DT/DV..

Helical gearmotor in B14 flange-mounted version

RM..DR/DT/DV..

B5 flange-mounted helical gearmotor with extended bearing

hub
