Unit designations MOVIMOT® standard design
Unit Designations and Versions
3.8 Unit designations MOVIMOT
®
standard design
Mechanical versions
Plug connector
Options
DT.. MM.., DV.. MM.. Foot-mounted version
..DT.. MM.., ..DV.. MM.. Attached motor for gear units
DFT.. MM.., DFV.. MM.. Flange-mounted version
DT..F MM.., DV..F MM.. Foot and flange-mounted version
/AVT1 M12 plug connector for RS-485 connection
/RE.A/ASA3 HAN
®
10ES plug connector with two-clip closure for power
/RE.A/ASA3/AVT1 HAN
®
10ES plug connector with two-clip closure for power and M12-plug
connector for RS-485 connection
/RE.A/AMA6 HAN
®
Modular plug connector with two-clip closure for power and RS-485
connection
/BMG Brake (noise-reduced)
../HF .. with lock-type manual brake release
../HR .. with automatic manual brake release
/RS Backstop
/LN Low-noise fan guard
/Z Additional flywheel mass (flywheel fan)
/C Protection canopy for the fan guard
/ES..2 Encoder with spreadshaft, HTL signals, either 1 or 2 pulses per revolution
/ES..6 Encoder with spreadshaft, HTL signals, 6 pulses per revolution
/NV1.. Proximity sensor with A track
/NV2.. Proximity sensor with A and B tracks
/R..A/../BGM Brake control system
/R..A/../BSM Brake control system
/R..A/../URM Fast excitation brake
/MLU..A DC 24 V supply
/MLG..A Speed control module with DC 24 V supply
/MBG11A Setpoint generator
/MWA21A Setpoint converter
/MDG11A Diagnostic unit
/MF... Fieldbus interfaces
/MQ... MQ.. intelligent fieldbus modules
