Examples for the unit designation of AC (brake) motors

Unit Designations and Versions

3.7 Examples for the unit designation of AC (brake) motors

DT 90S 4 / BMG/ TF/ IS

Motor option IS integrated plug connector

Motor option: TF thermistor sensor

Motor option BMG brake

Size 90S, 4-pole

DT = Foot-mounted motor

DFV 132M 2 / BM / TF / ABB8 / EV1T

Motor option 5 V TTL incremental encoder EV1T

Motor option ABB8 plug connector

Motor option: TF thermistor sensor

Motor option BM brake

Size 132M, 2-pole

DFV = Flange-mounted motor

DV 112M 4-F / RS/ Z / C

Motor option protective canopy C

Motor option additional flywheel mass Z

Motor option backstop RS

Size 112M, 4-pole and foot/flange mounted motor

(DV..-F)

DV..-F = Foot/flange mounted motor
