Unit designations for AC motors and options
Unit Designations and Versions
Plug connector on AC motor options
/IS Integrated plug connector
/AMA.. HAN modular 10B plug connector on terminal box with two-clamp closure
/AMB.. HAN modular 10B plug connector on terminal box with two-clamp closure and EMC
housing
/ASA.. HAN modular 10ES plug connector on terminal box with two-clamp closure
/ASB.. HAN modular 10ES plug connector on terminal box with two-clamp closure and EMC
housing
/ACA.. HAN modular 10E plug connector on terminal box with two-clamp closure
/ACB HAN modular 10E plug connector on terminal box with two-clamp closure and EMC
housing
/ASE.. HAN modular 10ES plug connector on terminal box with one-clamp closure and EMC
housing
Encoder on AC motor options
/AV1Y Multi-turn absolute encoder with solid shaft, MSI and sin/cos signals
/AV1H Multi-turn absolute encoder with solid shaft, Hiperface
®
and sin/cos signals
/AS..H Multi-turn absolute encoder with spreadshaft, Hiperface
®
and sin/cos signals
/ES..H Single-turn absolute encoder with spreadshaft, Hiperface
®
and sin/cos signals
/ES..T Encoder with spreadshaft, TTL (RS-422), signals
/ES..S Encoder with spreadshaft, sin/cos signals
/ES..R Encoder with spreadshaft, TTL (RS-422), signals
/ES..2 Encoder with spreadshaft, HTL signals, either 1 or 2 pulses per revolution
/ES..6 Encoder with spreadshaft, HTL signals, 6 pulses per revolution
/EV1T Encoder with solid shaft, TTL (RS-422), signals
/EV1S Encoder with solid shaft, sin/cos signals
/EV1R Encoder with solid shaft, TTL (RS-422), signals
/EV1H Single-turn absolute encoder with solid shaft, Hiperface
®
and sin/cos signals
/EH1T Encoder with hollow shaft, TTL (RS-422), signals
/EH1S Encoder with hollow shaft, sin/cos signals
/EH1R Encoder with hollow shaft, TTL (RS-422), signals
/NV1.. Proximity sensor with A track
/NV2.. Proximity sensor with A and B tracks
Mounting device for encoders on AC motor options
ES..A .. with spreadshaft
EV1A .. with solid shaft
