Unit designations for AC motors and options
Unit Designations and Versions
3.5 Unit designations for AC motors and options
Standard AC motor of the series
DT.., DV.. Foot-mounted version
DR.., ..DT.., ..DV.. Attached motor for gear units
DFR.., DFT..,
DFV..
Flange-mounted version
DT..F, DV..F Foot and flange-mounted version
Multi-speed AC motors with soft start
SDT.., SDV.. Foot-mounted version
SDFT.., SDFV.. Flange-mounted version
SDT..F, SDV..F Foot and flange-mounted version
Motor options
/BR, /BM(G) Brake (noise-reduced)
../HF .. with lock-type manual brake release
../HR .. with automatic manual brake release
/MM.. MOVIMOT
®
(integrated frequency inverter)
/MSW.. MOVI-SWITCH
®
(integrated switching and protection function)
/LN Low-noise fan guard for motor sizes 71 to 132S
/RS Backstop
/TF Thermistor (PTC resistor)
/TH Thermostat (bimetallic switch)
/U Non-ventilated
/VR Forced cooling fan, 1 × DC 24 V
/VR Forced cooling fan, 1 × 100 ... AC 240 V, 50/60 Hz (with UWU52A)
/VS Forced cooling fan, 1 × 220 ... AC 266 V, 50 Hz/60 Hz, 1 x 115V
/V Forced cooling fan, 3 × AC 380 ... 415 V, 50 Hz/60 Hz, 3 x AC, 460V
/Z Additional flywheel mass (flywheel fan)
/C Protection canopy for the fan guard
