Manual – Gear Units and Gearmotors
Unit designations for components on the input side
Unit Designations and Versions
3.2 Unit designations for components on the input side
Adapter
AM.. Adapter for mounting IEC/NEMA motors
../RS ..and backstop
AQ.. Adapter for mounting servomotors
AQA with keyway
AQH with clamping ring hub
AR.. Adapter with torque limiting coupling
../W ..and speed monitoring
../WS ..and slip monitoring
AT .. Adapter with hydraulic centrifugal coupling
../RS ..and backstop
../BM(G) ..and disc brake
../HF ..with manual brake release, lockable
../HR ..with automatic manual brake disengaging
Input shaft
assembly
AD .. Input shaft assembly
../P ..with motor mounting platform
../RS ..with backstop
../ZR ..with centering shoulder
3.3 Unit designations for the swing base
MK.. Swing base
../MTS Mechanical thermal monitoring unit
../BTS Proximity-type thermal monitoring unit
../T Torque arm
