Manual – Gear Units and Gearmotors
Unit designations for gear units and options
Unit Designations and Versions
3 Unit Designations and Versions
3.1 Unit designations for gear units and options
Helical gear units
RX.. Single-stage foot mounted version
RXF.. Single-stage B5 flange-mounted version
R.. Foot-mounted version
R..F Foot-mounted and B5 flange-mounted version
RF.. B5 flange-mounted version
RZ.. B14 flange-mounted version
RM.. B5 flange-mounted version with extended bearing housing
Parallel shaft
helical gear units
F. . Foot-mounted version
FA..B Foot-mounted version and hollow shaft
FH..B Foot-mounted and hollow shaft with shrink disc
FV..B Foot-mounted version and hollow shaft with splined hollow shaft to DIN 5480
FF.. B5 flange-mounted version
FAF.. B5 flange-mounted version and hollow shaft
FHF.. B5 flange-mounted and hollow shaft with shrink disc
FVF.. B5 flange-mounted version and hollow shaft with splined hollow shaft to DIN 5480
FA.. Hollow shaft
FH.. Hollow shaft with shrink disc
FT.. Hollow shaft with TorqLOC
®
hollow shaft mounting system
FT..B Foot-mounted hollow shaft with TorqLOC
®
hollow shaft mounting system
FV.. Hollow shaft with splined hollow shaft to DIN 5480
FAZ.. B14 flange-mounted version and hollow shaft
FHZ.. B14 flange-mounted and hollow shaft with shrink disc
FVZ.. B14 flange-mounted version and hollow shaft with splined hollow shaft to DIN 5480
Helical-bevel gear
units
K.. Foot-mounted version
KA..B Foot-mounted version and hollow shaft
KH..B Foot-mounted version and hollow shaft with shrink disc
KV..B Foot-mounted version and hollow shaft with splined hollow shaft to DIN 5480
KF.. B5 flange-mounted version
KAF.. B5 flange-mounted version and hollow shaft
KHF.. B5 flange-mounted and hollow shaft with shrink disc
KVF.. B5 flange-mounted version and hollow shaft with splined hollow shaft to DIN 5480
KA.. Hollow shaft
