Manual – Gear Units and Gearmotors

Position terminal box and cable entry (MOVIMOT® drives)

Mounting Positions and Important Order Information

00007102

Figure 94: Possible terminal box positions F..D..MM..

Gear unit Motor AC 0° 90° 180° 270°

F27

DT71D MM..

∅ 4.72in

2) 2)

FF27

DT71D MM..

∅ 4.72inDT80..MM..

2) 2)

DT80..MM..

DT90..MM..

2) 2) 2) 2)

DT90..MM..

F37

DT71D MM..

∅ 4.72in

2) 2)

FF37

DT71D MM..

∅ 4.72in

DT80..MM..

2) 2)

DT80..MM..

DT90..MM..

2) 2)

DT90..MM..

DV100..MM..

2) 2)

DV100..MM..

F47

DT71D MM..

∅ 4.72in

2) 2)

FF47

DT71D MM..

∅ 4.72in

DT80..MM..

2) 2)

DT80..MM..

DT90..MM..

2) 2)

DT90..MM..

DV100..MM..

2) 2)

DV100..MM..

F57

DT71D MM..

∅ 6.30in

2) 2)

FF57

DT71D MM..

∅ 6.30in

DT80..MM..

2) 2)

DT80..MM..

DT90..MM..

2) 2)

DT90..MM..

DV100..MM..

2) 2)

DV100..MM..

F67

DT71D MM..

∅ 6.30in

2) 2)

FF67

DT71D MM..

∅ 6.30in

DT80..MM..

2) 2)

DT80..MM..

DT90..MM..

2) 2)

DT90..MM..

DV100..MM..

2) 2)

DV100..MM..

F77

DT80..MM..

∅ 7.87in

2) 2)

FF77

DT80..MM..

∅ 7.87inDT90..MM..

2) 2)

DT90..MM..

DV100..MM..

2) 2)

DV100..MM..

F87

DT80..MM..

∅ 9.84in FF87

DT80..MM..

∅ 9.84inDT90..MM1..

2) 2)

DT90..MM1..

DV100..MM..

2) 2)

DV100..MM..

F97

DT90..MM1..

∅ 11.81in FF97

DT90..MM1..

∅ 11.81in

DV100..MM.. DV100..MM..

F107 DV100..MM.. ∅ 13.78in FF107 DV100..MM.. ∅ 13.78in

1) Standard position

2) The gear unit must be mounted on a base if the inverter is on the foot-mounting end

Possible terminal box position

When using plug connectors/MOVIMOT

options, the number of possible positions can be even more limited. Please contact

SEW-EURODRIVE.

M1…M6M1 … M6
