Technical data

9
180
Manual – Gear Units and Gearmotors
Position terminal box and cable entry (MOVIMOT® drives)
Mounting Positions and Important Order Information
9.11 Position terminal box and cable entry (MOVIMOT
®
drives)
00005102
Figure 92: Possible terminal box positions RX..D..MM..
AC
AC
Gear unit Motor AC 0° 90° 180° 270°
1)
Gear unit Motor AC 0° 90° 180° 270°
1)
RX57
DT71D MM..
∅ 6.30in
2)
RXF57
DT71D MM..
∅ 6.30in
DT80..MM..
2)
DT80..MM..
DT90..MM..
2)
DT90..MM..
DV100..MM..
2)
DV100..MM..
RX67
DT71D MM..
∅ 6.30in
2)
RXF67
DT71D MM..
∅ 6.30in
DT80..MM..
2)
DT80..MM..
DT90..MM..
2)
DT90..MM..
DV100..MM..
2)
DV100..MM..
RX77
DT80..MM..
∅ 7.87in
2)
RXF77
DT80..MM..
∅ 7.87inDT90..MM..
2)
DT90..MM..
DV100..MM..
2)
DV100..MM..
RX87
DT80..MM..
∅ 9.84in RXF87
DT80..MM..
∅ 9.84inDT90..MM1..
2)
DT90..MM1..
DV100..MM..
2)
DV100..MM..
RX97
DT80..MM..
∅ 11.81in
RXF97
DT80..MM..
∅ 11.81inDT90..MM1.. DT90..MM1..
DV100..MM.. DV100..MM..
RX107 DV100..MM.. ∅ 13.78in RXF107 DV100..MM.. ∅ 13.78in
1) Standard position
2) Gear unit must be mounted on a base
Possible terminal box position
When using plug connectors/MOVIMOT
®
options, the number of possible positions can be even more limited. Please contact
SEW-EURODRIVE.
M1…M6M1 … M6
