Extended storage
Product Description
2.4 Extended storage
Type You can also order the gear units prepared for "extended storage". SEW-EURODRIVE
recommends the "extended storage" type for storage periods longer than 9 months.
In this case, a VCI (v
olatile corrosion inhibitor) is added to the lubricant in these gear
units. Please note that this VCI corrosion inhibitor is only effective in a temperature
range of -25 °C...+50 °C. The flange contact surfaces and shaft ends are also treated
with an anti-corrosion agent. If not specified otherwise in your order, the gear unit will be
supplied with OS1 surface protection. You can order OS2, OS3 or OS4 instead of OS1.
Storage
conditions
For extended storage, observe the storage conditions specified in the following table:
The gear units must remain tightly sealed until taken into operation to prevent the VCI
corrosion protection agent from evaporating.
Gear units will be supplied with an oil fill according to the mounting position (M1 ... M6)
and are ready for operation. Check the oil level before you start operating the gear unit
for the first time!
Climate zone Packaging
1)
Storage location
2)
Storage duration
Temperature (Europe,
USA, Canada, China
and Russia, excluding
tropical zones)
Packed in containers, with
desiccant and moisture
indicator sealed in the
plastic wrap.
With roof, protected against rain and
snow, no shock loads
Up to three years with regular checks
to the packaging and moisture indica-
tor (rel. humidity < 50%).
open
Under roof, enclosed at constant tem-
perature and atmospheric humidity
(5
°C < ϑ < 60°C, < 50% relative atmo-
spheric humidity). No sudden tempera-
ture fluctuations and controlled
ventilation with filter (free of dust and
dirt). No aggressive vapors and no
shocks.
Two years or more given regular
inspections. During inspection, check
for cleanliness and mechanical dam-
ages. Check corrosion protection.
Tropical (Asia, Africa,
Central and South
America, Australia, New
Zealand excluding tem-
perate zones)
Packed in containers, with
desiccant and moisture
indicator sealed in the
plastic wrap. Protected
against insect damage
and mold through chemi-
cal treatment.
Under roof, protected against rain, no
shock loads.
Up to three years with regular checks
of the packaging and moisture indica-
tor (rel. humidity < 50%).
open
Under roof, enclosed at constant tem-
perature and atmospheric humidity
(5
°C < ϑ < 50°C, < 50% relative atmo-
spheric humidity). No sudden tempera-
ture fluctuations and controlled
ventilation with filter (free of dust and
dirt). No aggressive vapors and no
shock loads. Protection against insect
damage.
Two years or more given regular
inspections. During inspection, check
for cleanliness and mechanical dam-
ages. Check corrosion protection.
1) Packaging must be performed by an experienced company using the packaging materials that have been expressly specified for the
particular application.
2) SEW-EURODRIVE recommends to store the gear units according to the mounting position.
