Technical data

9
154
Manual – Gear Units and Gearmotors
Important order information
Mounting Positions and Important Order Information
Sample orders
Change in
mounting
position
Make sure to read the following information when you operate the gearmotor in a
mounting position other than the one indicated in the order:
• Adjust lubricant fill quantity to match the new mounting position
• Adjust position of breather valve
• For helical-bevel gearmotors: Contact the SEW-EURODRIVE customer service prior
to changing to mounting position M5 or M6 and when changing from M5 to M6 or vice
versa.
• For helical-worm gearmotors: Contact the SEW-EURODRIVE customer service
when changing to mounting position M2.
Type
(Examples)
Mounting
position
Shaft
position
Flange
position
Terminal
box
position
Position of
cable entry
Direction of
rotation of
output
K47../RS M2 A - 0° "X" CW
SF77DV100L4 M6 AB AB 90° "3" -
KA97DV132M4 M4 B - 270° "2" -
KH107DV160L4 M1 A - 180° "3" -
WF20DT71D4 -AA0°"X"-
KAF67A M3 A B - - -
M1…M6M1 … M6
