Operation on inverter
Project Planning for AC Motors with Inverter
Product
characteristics
The following table lists the most important product characteristics for the various
inverter series. The overview of product characteristics can help you to choose the
suitable inverter series for your application.
Product characteristics MOVITRAC
®
B MOVIDRIVE
®
MDX60/61B
Voltage range
1 × 200 ... 240 V
AC
(limited power
range)
3 × 200 ... 240 V
AC
(limited power
range)
3 × 380 ... 500 V
AC
3 × 200 ... 240 V
AC
(limited power
range)
3 × 380 ... 500 V
AC
Power range 0.3-175HP 0.75-175HP
Overload capacity
150% I
N
1)
briefly and 125% I
N
permanently during operation without
overload
1) Only for MOVIDRIVE
®
MDX60/61B: The short-time overload capacity is 200% I
N
for units of size 0 (0005
...0014).
4Q capable Yes, with integrated brake chopper as standard.
Integrated line filter
At 1 × 200 ... 240 V
AC
: according
to class B limit
At 3 × 200 ... 240 V
AC
und 3 ×380
... 500 V
AC
: sizes 0, 1 and 2
according to class A limit
Sizes 0, 1 and 2
according to class A limit
TF input Yes
Control mode
U/f or voltage-controlled flux vec-
tor control (VFC)
U/f or voltage-controlled flux vec-
tor control (VFC), with speed
feedback speed control and cur-
rent-controlled flux vector control
(CFC).
Speed feedback No Option
Integrated positioning and
sequence control system
No Standard
Serial interfaces
System bus (SBus)
and RS-485
Fieldbus interfaces
Optional via gateway PROFIBUS,
INTERBUS, CANopen, Devi-
ceNet, Ethernet
Optional PROFIBUS-DP, INTER-
BUS, INTERBUS LWL,
CANopen, DeviceNet, Ethernet
Technology options IEC 61131 control
Input/output card
Synchronous operation
Absolute encoder card
IEC 61131 control
Safe stop Yes Yes
Approvals UL and cUL approval, C-tick
