Technical data

8
142
Manual – Gear Units and Gearmotors
Operation on inverter
Project Planning for AC Motors with Inverter
8 Project Planning for AC Motors with Inverter
8.1 Operation on inverter
Range of
products
The extensive product range of SEW-EURODRIVE inverters is available for designing
electronically controlled drives. SEW-EURODRIVE offers the following inverter series:
• MOVITRAC
®
B: Compact and inexpensive frequency inverter for the power range
0.3-175HP. Single-phase and three-phase supply connection for 230 V
AC
and three-
phase supply connection for 460 V
AC
.
• MOVIDRIVE
®
MDX60/61B: High-performance drive inverter for dynamic drives in
the power range 0.75-175HP. Great diversity of applications due to extensive-
expansion options with technology and communication options. Three phase supply
connection for 230 V
AC
and 460 V
AC
59188AXX
Figure 79: Range of inverters for AC motors
MOVITRAC
®
B
MOVIDRIVE
®
MDX60/61B
