General notes on product description

Product Description

Brake motors On request, motors and gearmotors can be supplied with an integrated mechanical

brake. The SEW-EURODRIVE brake is an electromagnetic disk brake with a DC coil

that releases electrically and brakes using spring force. Due to its operating principle,

the brake is applied if the power fails. It meets the basic safety requirements. The brake

can also be released mechanically if equipped with a manual brake release. You will re-

ceive a manual lever with automatic reset. The brake is controlled by a control module

that is either installed in the motor conduit box or the control cabinet.

A significant feature of the brakes is their very short length. The brake bearing end shield

is an integral part of both the motor and the brake. The integrated construction of the

SEW-EURODRIVE brake motor permits particularly compact and sturdy solutions.

International

markets

SEW-EURODRIVE supplies motors with CSA certification meeting the connection re-

quirements to CSA und NEMA guidelines. UL listed motors are available when request-

ed.

We deliver UL listed MOVIMOT

drives with connection requirements according to

NEMA guidelines.

For the Japanese market, SEW-EURODRIVE offers motors conforming to JIS standard.

Contact your sales representative to assist you in such cases.

Component on

the input side

The following components on the input side are available for the gear units from SEW-

EURODRIVE:

• Input covers with input shaft extension, optionally with

– Centering shoulder

– Backstop

– Motor mounting platform

• Adapter

– for mounting IEC or NEMA motors with the option of a backstop

– for mounting servomotors with a square flange

– with torque limiting safety couplings and speed or slip monitor

– with hydraulic centrifugal coupling, also with disc brake or backstop

Swing base A swing base is a drive unit consisting of helical-bevel gear unit, optional fluid coupling

and electric motor. The complete arrangement is mounted to a rigid mounting rail.

Motor swings are available with the following optional accessories:

• Torque arm

• Mechanical thermal monitoring unit (fluid coupling option)

• Contactless thermal monitoring unit (fluid coupling option)
