MOVIMOT® (→ MM)
Project Planning for AC Motors
• Control takes place via binary signals, via the serial interface RS-485 or optionally
via all commercial fieldbus interfaces (PROFIBUS, INTERBUS, DeviceNet,
CANopen or AS-interface).
• Overview of MOVIMOT
®
functions (all versions):
– Clockwise, counterclockwise operation
– Changeover between two fixed setpoints
– Setpoint f1 can be scaled
– Ready signal to controller
– Diagnostics of MOVIMOT
®
via status LED
– Additional functions for specific applications
• Additional functions of version with integrated AS-interface
– Addressing via M12 (AS-interface address 1-31)
– Connection option for two external sensors
– Additional LED for AS-interface status
– Additional diagnostic interface via modular jack 4/4 plug connector
• MOVIMOT
®
is supplied with UL approval (UL listed) on request.
Advantages of
MOVIMOT
®
MOVIMOT
®
offers the following advantages:
• Compact design
• Interference-free connection between inverter and motor
• Closed design with integrated protection functions
• Inverter cooling independent of the motor speed
• No space required in the control cabinet
• Optimum presetting of all parameters for the expected application
• Compliance with EMC standards EN 50 081 (interference suppression level A) and
EN 50 082
• Easy installation, startup and maintenance
• Easy to service for retrofitting and replacement
MOVIMOT
®
can be used to equip extensive systems or can be integrated into existing
systems. MOVIMOT
®
is also the electronic replacement for multi-speed motors or me-
chanical variable speed drives.
MOVIMOT
®
is available as motor, brake motor, gearmotors or geared brake motor in
many different standard versions and mounting positions.
