Technical data

7
124
Manual – Gear Units and Gearmotors
Encoders and prefabricated cables for encoder connection (→ GM)
Project Planning for AC Motors
Prefabricated cables for incremental TTL sensors and sin/cos encoders (TTL sensors
and sin/cos encoders) with 24V voltage supply:
Prefabricated cables for HIPERFACE
®
encoders:
Extension cables for HIPERFACE
®
cables
3
Part number 1332 459 4 1332 458 6
Installation Fixed installation Cable carrier installation
for encoder ES1S, ES2S, EV1S, EH1S, ES1R, ES2R, EV1R, EH1R
Cable cross section 4×2×0.25 mm
2
(AWG23) + 1×0.25 mm
2
(AWG23)
Conductor colors
A: Yellow (YE)
A: Green (GN)
B : Red (RD)
B : Blue (BU)
C : Pink (PK)
C : Gray (GY)
UB: White (WH)
⊥: Brown (BN)
Sensor cable: Violet (VT)
Manufacturer and type
Lapp
Helukabel
Unitronic Li2YCY (TP)
Paar-Tronic-CY
Unitronic LiYCY
Super-Paar-Tronic-C-PUR
For inverter MOVIDRIVE
®
MDX61B with DEH11B option
Connection on
encoder / motor
Inverter
with conductor end sleeves
Cut off the violet conductor (VT) of the cable at the encoder end.
with 15-pin sub D plug
Part number 1332 453 5 1332 455 1
Installation Fixed installation Cable carrier installation
for encoder ES3H, ES4H, AS3H, AS4H, AV1H
Cable cross section 6 × 2 × 0.25 mm
2
(AWG 23)
Conductor colors
cos+: Red (RD)
cos-: Blue (BU)
sin+: Yellow (YE)
sin-: Green (GN)
D+: Black (BK)
D-: Violet (VT)
TF/TH/KTY+: Brown (BN)
TF/TH/KTY-: White (WH)
GND: Gray/pink + pink (GY-PK + PK)
U
S
: Red/blue + gray (RD-BU + GY)
Manufacturer and type Lapp, PVC/C/PP 303 028 1 Nexans, 493 290 70
For inverter MOVIDRIVE
®
MDX61B with DEH11B option
Connection on
encoder / motor
Inverter
With 12-pin round connector plug
(Intercontec, type ASTA021NN00 10 000 5 000)
with 15-pin sub D plug
Part number 199 539 1 199 540 5
Installation Fixed installation Cable carrier installation
Cable cross section 6 × 2 × 0.25 mm
2
(AWG 23)
Conductor colors → HIPERFACE
®
cable
Manufacturer and type Lapp, PVC/C/PP 303 028 1 Nexans, 493 290 70
Connection on
encoder / motor
HIPERFACE
®
cable
With 12-pin round connector plug
(Intercontec, type ASTA021NN00 10 000 5 000)
with 12-pin round connector plug (Intercontec, type AKUA20)
