Encoders and prefabricated cables for encoder connection (→ GM)
Project Planning for AC Motors
Prefabricated cables for encoder connection:
Prefabricated cables for incremental TTL encoders with 5V voltage supply:
1
Part number 817 957 3
Installation Fixed installation
for encoders with
5 V voltage supply
ES1T, ES2T, EV1T, EH1T
Cable cross section 4×2×0.25 mm
2
(AWG23) + 1×0.25 mm
2
(AWG23)
Conductor colors
A: Yellow (YE)
A: Green (GN)
B : Red (RD)
B : Blue (BU)
C : Pink (PK)
C : Gray (GY)
UB: White (WH)
⊥: Brown (BN)
Sensor cable: Violet (VT)
Manufacturer and type
Lapp
Helukabel
Unitronic Li2YCY (TP)
Paar-Tronic-CY
For inverter MOVIDRIVE
®
MDX61B with DEH11B option
Connection
on the DWI11A
on the inverter
with 9-pin sub D socket
with 15-pin sub D plug
2
Part number 198 829 8 198 828 X
Installation Fixed installation Cable carrier installation
for encoder ES1T, ES2T, EV1T, EH1T via DWI11A and cable 817 957 3
Cable cross section 4×2×0.25 mm
2
(AWG23) + 1×0.25 mm
2
(AWG23)
Conductor colors
A: Yellow (YE)
A: Green (GN)
B : Red (RD)
B : Blue (BU)
C : Pink (PK)
C : Gray (GY)
UB: White (WH)
⊥: Brown (BN)
Sensor cable: Violet (VT)
Manufacturer and type
Lapp
Helukabel
Unitronic Li2YCY (TP)
Paar-Tronic-CY
Unitronic LiYCY
Super-Paar-Tronic-C-PUR
For inverter MOVIDRIVE
®
MDX61B with DEH11B option
Connection on
encoder / motor
DWI11A
with conductor end sleeves
Connect the violet conductor (VT) with the encoder at UB.
with 9-pin sub D plug
