Manual – Gear Units and Gearmotors
Encoders and prefabricated cables for encoder connection (→ GM)
Project Planning for AC Motors
Prefabricated
cables for
encoder
connection
SEW-EURODRIVE offers prefabricated cables for simple and reliable connection of
encoder systems. It is necessary to differentiate between cables used for fixed installa-
tion or for use in cable carriers. Contact SEW-Eurodrive concerning availability and
length.
06608AXX
Figure 60: Prefabricated cables for encoder connection and encoder
06607BXX
Figure 61: Prefabricated cables for HIPERFACE
®
encoders
X2: Encoder
X1: MOVIDRIVE
DWI
2
ES1T, ES2T,
EV1T, EH1T
DWI11A
ES1S, ES2S, EV1S, EH1S
ES1R, ES2R, EV1R, EH1R
MOVIDRIVE
MCH4_A
®
compact
MOVIDRIVE
MCH4_A
®
compact
MOVIDRIVE
MDX61B
®
MOVIDRIVE
MDX61B
®
DEH11BDEH11B
3
1
DEH11B
ES3H, ES4H,
AS3H, AS4H,
AV1H
MOVIDRIVE
MCH4_A
®
compact
MOVIDRIVE
MDX61B
®
4
