Encoders and prefabricated cables for encoder connection (→ GM)
Project Planning for AC Motors
7.13 Encoders and prefabricated cables for encoder connection (→ GM)
Tachometer Various types of tachometers are available for installation on DT../ DV.. AC motors as
standard depending on the application and motor size. With rare exceptions, the encod-
ers can be combined with other optional components installed in the motor, such as
brakes and forced cooling fans.
Overview of
encoders
GM
Name For motor Encoder type Shaft Specification Power supply Signal
EH1T
DR63
Encoders
Hollow shaft
1024 pulses/rev-
olution
DC 5 V controlled TTL/RS-422
EH1S
9 V
DC
... 26 V
DC
1 V
SS
sin/cos
EH1R TTL/RS-422
ES1T
DT71...DV100
Spreadshaft
DC 5 V controlled TTL/RS-422
ES1S
9 V
DC
... 26 V
DC
1 V
SS
sin/cos
ES1R TTL/RS-422
ES2T
DV112...DV132S
DC 5 V controlled TTL/RS-422
ES2S
9 V
DC
... 26 V
DC
1 V
SS
sin/cos
ES2R TTL/RS-422
EV1T
DT71...DV280 Solid shaft
DC 5 V controlled TTL/RS-422
EV1S
10 V
DC
... 30 V
DC
1 V
SS
sin/cos
EV1R TTL/RS-422
ES12 DT71...DV100
Encoder Spreadshaft A+B tracks 9 V
DC
... 26 V
DC
Either 1 or 2 pulses/rev-
olution
ES22 DV112...DV132S
ES16 DT71...DV100
6 pulses/revolution
ES26 DV112...DV132S
NV11
DT71...DV100
Proximity sensor Solid shaft
A track
10 V
DC
... 30 V
DC
1 pulse/revolution, nor-
mally open contact
NV21 A+B tracks
NV12
DT71...DV132S
A track
2 pulses/revolution, nor-
mally open contact
NV22 A+B tracks
NV16 A track
6 pulses/revolution, nor-
mally open contact
NV26 A+B tracks
AV1Y DT71...DV280
Multi-turn-
absolute
encoder
Solid shaft - 10 V
DC
... 30 V
DC
MSSI interface and
1 V
SS
sin/cos
ES3H DT71...DV100 Single-turn
HIPERFACE
®
encoder
Spreadshaft - 7 V
DC
... 12 V
DC
RS-485 interface and 1
V
SS
sin/cos
ES4H DV112...DV132S
AS3H DT71...DV100 Multi-turn
HIPERFACE
®
encoder
AS4H DV112...DV132S
AV1H
1)
DT71...DV280
Multi-turn
HIPERFACE
®
encoder
Solid shaft - 7 V
DC
... 12 V
DC
RS-485 interface and 1
V
SS
sin/cos
1) recommended encoder for operation with MOVIDRIVE
®
MDX61B with option DEH11B
