User guide

The Eagle Manual
5
Mount definitions
A system consists of several components
Connector Weather Cover
Mounting Feet
Mount or Azimuth Base
LNB Arm Assembly
Note: Your LNB
may vary from the
one pictured
depending upon your
system configuration.
Reflector/Parabola
MOUNT (ODU)
Items included with the system and
are not shown.
1 ea LNB Landing Plate
15' Control Cable, 25'
1 ea Connector, green, 12 pin
1 ea Power Supply, 12 VDC 7 amp
1 ea RE-1000 User Guide
1 ea EAGLE Controller
Clam Shell
