USER MANUAL – Mantis™ II 433.92 MHz Reader
3. Firmware
L
NOTE – The Mantis™ II Reader can only be configured through an
Ethernet connection via the RJ-45 jack on the rear of the Reader.
U
WARNING – When an Ethernet connection is made directly between
the Reader and a PC, a cross-over network cable is necessary.
File System
All embedded operating systems, signal processing software, and
configuration options of the Mantis™ II 433.92 MHz Reader are stored in
a flash-based file system internal to the Reader. If any changes or updates
are required, the files are collected in a directory on the PC, packaged into a
new file system, and then transferred to the Reader by TFTP (Trivial File
Transfer Protocol).
Upgradeable Firmware
The Mantis™ II 433.92 MHz Reader has the ability to be updated as new
firmware is released. It is vital these updates be obtained directly from RF
Code™ or its authorized source, since these files define the operation of the
Reader and if defective, the files will render the Reader inoperable.
U
WARNING – Firmware updates should be obtained directly from RF
Code™ or its authorized source. If defective, these files will render
the Mantis™ II Reader inoperable.
