USER MANUAL – Mantis™ II 433.92 MHz Reader

Network Settings

MAC Addr

Reader MAC address.

• Displays the MAC address of the Reader. This field is informational

only and cannot be modified.

(I)P Addr I

I – Change network IP address.

• Enter in normal dotted decimal format, e.g.: 192.168.1.129

• An error message is displayed if the format is unintelligible or the

numbers are out of range.

• This entry represents the new IP address that will be assigned to the

Reader during an upload.

WARNING – Microsoft Windows-based PCs have restrictions on

certain IP address ranges (e.g. 127.x.x.x and 224.x.x.x through

254.x.x.x). Since addresses fitting these parameters cannot be

configured on a Windows-based PC, it will not be possible to use the

configuration utility to reconfigure a Reader that has been assigned

an address within this scope.

(S)ubnet S

S – Change subnet mask.

• Enter in normal dotted decimal format, e.g.: 255.255.255.0

• An error message is displayed if the format is unintelligible or the

numbers are out of range.

(G)ateway Addr G

G – Change gateway address.

• Enter in normal dotted decimal format, e.g.: 192.168.1.1

• An error message is displayed if the format is unintelligible or the

numbers are out of range.

(P)ing TFTP IP Addr P

P – Pings the TFTP IP address.

• An error message is displayed if the TFTP IP address is blank.

• A status message is displayed which reflects the results of the pinging

operation.

• If a ping is unsuccessful, the utility will attempt to remove the TFTP IP

address from the ARP table and perform another ping.
