5.2 Address Assignment
Setting IP Address
With the 8-pin address switch you can set the IP address of the
Gateways.
You can set values in binary format between 0-255.
Assigning IP Address
manually:
◦ Set any address between 1-254
ð The gateway component uses the address 192.168.1.X with the net
mask 255.255.255.0 and gateway 192.168.1.1
◦ Open the website http://192.168.1.X
◦ Log on:
Logon data for the initial logon :
User: Admin
Password: 1701
◦ Click on the "Change Configuration" button
◦ Set the IP address required
◦ Confirm your entry by pressing the "Apply" button
◦ Set all address switches to "0"
◦ Restart the gateway component by switching this off and then on again.
ð The set IP address is now used.
Receiving IP Address from
the DHCP Server
◦ Set the value "255" (all switches in the direction of the numbers) to
activate the DHCP mode.
ð Assign the IP address automatically from the DHCP server.
Setting IP Address using the
Master Software
◦ Set the value "0" (all switches to "Off")
ð The gateway component uses the IP address that was last set using
the software.
◦ You can change this IP address at any time via the EtherNet/IP-
protocol or website.
◦ Restart the gateway component by switching this off and then on again.
ð The set IP address is now used.
