Specifications

The
peak
led
in the
channelrnodule rnonitors
signal
level on 4
points
in
the channel.
The
MUTE
ry"tern is a special
soft-muting systern
controlled
either by
the local rnute switch
or by
the
rnute
cornputer located
in
the
master section.
Low
intensity
rnuting
will indicate that
the
rnute
function
can be controlled
by the
rnute cornputer. The SAI1E
switch
prevents
the
rnute
being
controlled
by the rnute computer.
3.6 THE
EAI}ER VCA
SECTION
The Axion has
a high
quality
l00rnrn
ALPS fader, P&G faders
are
optionally available.
The lineair
fader
controls
a high
quahty
dbx
VCA which
in
turn
can
be controlled
by . group rnaster fader, if
the channel
is assigned to
such a
fader.
Assignment of the channel VCA
fader
is
as follows.
By hitting the
*VCA"
select
switch
once,
one of the
led
indicators
1-8 will light,
indicating which
VCA
rnaster
is
selected.
By hitting
the VCA
select again the next
in
nurnber
VCA will
be selected.
ff
vca rnaster
8 is o[, the next selection
will
be vca nr
1 and so on.
If
you
wish
to
de-select
a channel
frorn a
vca
rnaster, sirnply
push
the
select switch
for rnore than 1 second
and
the assign
switch
will
turn
off
indicating
that the
local
fader has been
selected
for VCA
control.
NOTE: the
VCA rnax led
indicates
whether there is
still
gain
left
in
the
vca.
If the VCA is
corrtrolled
by
r rnaster VCA,
it
is very
easy to
"overload"
the
VCA by
bringlng
up
the rnaster
VCA fader
above
0
dB,
lets say
to
+5d8.
If the
channel
VCA fader
is already
set
to
+5dB
the
rnaxirnurn gain
of 10dB
is
already given away,
and
no exffa
gain
could
be
expected
frorn the
VCA, even
when
the
channel fader
indicates a further
5
dB
of
frontpnel
gain.
CHANNELMETERS
The Axion is shipped
wirh25
segrnent
ledbar
rneters
in
the stand-
ard
configuation.
The
first
LED
in the bargraph
is
a
power
supply
indicator.
3.7
INPUTMOI}ULEIN
Ah[I}
OUTPUT
CONNECTORS
Every charrnel
has
the
following
3 pin XLR connectors
at
the
back
of
the housing.
The
balanced
MIC input
The balanced
LINE
input
