Instructions / Assembly

A. Headboard Top (1 pc) B. Footboard (1 pc) C. Side Rail (2 pcs)

F. Wood Slat System (1 pc)

E. Center Rail (1 pc)

D. Leg (4 pcs)

G. Center Leg (3 pcs)

IMPORTANT NOTE:

Carefully remove all the parts from the box. Arrange on a at

surface and verify you have all of the following parts and hardware.

PARTS LIST

HARDWARE LIST

(Continued on back)

STEP 1

STEP 3

ASSEMBLY INSTRUCTIONS

STEP 2

TOOLS REQUIRED:

Phillips Screwdriver

Assemble the Legs (Part D) to the Headboard (Part A1) by turning the Legs clockwise

until tight. Assemble Headboard Top (Part A2) to Headboard bottom (Part A1) using

three 40mm Bolts (Part H), three Spring Washers (Part I) and three Flat Washers (Part J).

Use the small Hex Key (Part K) to secure the bolts.

Secure the Legs (Part D) into the Footboard (Part B) by turning

the Legs clockwise until tight. Attach the Center Legs (Part G) to

the Center Rail (Part E) using three 40mm Bolts (Part H). Secure

the bolts using the small Hex Key (Part K).

Attach the siderails (Part C) to the Headboard (Part A) and the

Footboard (Part B) by hanging the siderails onto the pre-attached

bolts on the Headboard and Footboard. Tighten the bolts using

the large Hex Key (Part L).

J. Flat Washer

(3 pcs)

I. Spring Washer

(3 pcs)

M. 16mm Screw

(2 pcs)

N. 32mm Screw

(9 pcs)

L. Large Hex Key

(1 pc)

H. 40mm Bolt

(6 pcs)

K. Small Hex Key

(1 pc)
