User Guide ReSound AzureTM BTE AZ70-DVI, AZ80-DVI
ReSound AzureTM Contents Your new digital ReSound Azure hearing instruments will enable you to hear sounds that you may not have heard in years because of your hearing loss. Practice and a positive attitude are important in learning to use hearing instruments. While some people adjust quickly to wearing hearing instruments in their ears and hearing the new sounds, other people may need more time. TM The intent of this user guide is to provide information on the many aspects of using hearing instruments.
Your ReSound Azure AZ70-DVI and AZ80-DVI Hearing Instrument 1. Programme Selector 2. Battery Compartment & On/Off Switch 3. Sound Outlet 4. 1 st Microphone Sound Inlet 5. 2nd Microphone Sound Inlet 6. Volume Control 7. Direct Audio Input 8. Left/Right indicator (Right=Red, Left=Blue) 9. Battery lock 10. Model 11.
Adjusting to a World of New Sounds New Sounds A hearing loss is typically acquired gradually over many years. You may have become accustomed to an everyday life with fewer sounds, which also means hearing less noise than people with normal hearing hear. How to adjust If you are inexperienced with hearing instruments it is advisable to: 1. Use your hearing instruments every day 2.
How to Use the Hearing Instrument On/Off Function 1) When the battery compartment is fully closed, the instrument is turned on and programme 1 will be activated 2) To turn the instrument off, open the battery compartment. Many individuals use their fingernail to pull it open. 3) The instrument is then switched off 4) Whenever you are not using the instrument, remember to turn it off to stop battery consumption.
Inserting the Instrument (with dome) 1) Place the hearing instrument behind the ear 2) Hold the flex tube where it bends and gently push the dome into your ear canal (the dome should be placed far enough into the ear that the flex tube lies flush with your head) 3) It is important that the tube and the dome fit correctly into your ear 4) When the dome is placed correctly, you should not be able to see the flex tube sticking out when you face a mirror Note You should never attempt to bend or modify the shape
Programme Selector You can have up to four different programmes on your hearing instrument. The selection of programmes can be changed by your hearing care professional. 1. You can switch between programmes by pushing the programme selector once 2. You will then hear one or more “beeps”. The number of beeps indicates which programme you have selected 3.
Telephone Use Your can use the telephone with your hearing instruments. Using the telephone while using your hearing instruments may require some practice. By selecting the optional telecoil programme you can improve understanding of speech when using a hearing instrument compatible tele phone. Rather than picking up the sound from the telephone, this programme only picks up the telephone’s magnetic signal and converts it to sound. Your hearing care professional can activate the telecoil.
Using tele-loop systems Many gathering places such as schools, theatre and houses of worship, are equipped with tele-loop systems. To take advantage of such a system, select the telecoil program to pick up direct sound. If the hearing instrument goes dead when the telecoil program is selected, the tele-loop system may not be turned on or not operating correctly.
Maintenance Cleaning the Earmould Daily Maintenance Replace text: It is important to keep your hearing instrument clean and dry every day. To clean the instrument, use a soft cloth. If the instrument has been exposed to high humidity or perspiration, use a drying kit that is available from your hearing care professional. The earmould should be cleaned regularly: 1. Remove the earmould and the tubing from the hearing instrument before you clean it To avoid the need for repairs: 1.
Cleaning the Flex Tube and Dome How to Mount the Dome The tube and the dome should be cleaned regularly: 1. Remove the tube from the instrument before cleaning by unscrewing it We recommend that your hearing care professional changes the dome for you, since failure to change the domes in accordance with the instructions could result in injury. If you choose to change the dome yourself: 2. Use a damp cloth to clean the tube and dome on the outside 3.
Tulip Dome The Tulip-Dome consists of two “leaves”. It is important that the largest “leaf” is the outermost “leaf” (A): 1. Push the largest “leaf” away from the Tube with your finger (B) 2. This will make the large “leaf” bend forward 3. Then you push it back and it will be placed on top of the smaller “leaf” (C) 4. Now the Tulip-Dome is ready for insertion (D) Replacing the Sound Outlet Filter Your ReSound Azure hearing instrument is equipped with a filter.
General Precautions 1. Do not leave your hearing instrument in the sun, near an open fire or in a hot, parked car 2. Do not wear your instrument while showering, swimming, in heavy rain or in a moist atmosphere such as steam bath or sauna 3. Should your instrument become moist, put it in a closed container with a drying agent. Your hearing care professional can provide a specially designed container, a so called desiccator for this purpose 4.
26 Repairs Technical Data If your ReSound hearing instrument malfunctions it must be repaired by a qualified technician. Do not attempt to open the case of the hearing instrument since this will invalidate the warranty. If your hearing instrument requires service, please contact your hearing care professional for assistance.
Troubleshooting Guide 28 SYMPTOM CAUSE POSSIBLE REMEDY No sound • • • • • • Not turned on Dead single use battery Dead rechargeable battery Battery improperly inserted Blocked earmould or tube Blocked sound outlet filter • • • • • • Turn on by closing the battery door Replace battery Recharge battery Insert battery properly Clean earmould or tube blockage Change filter or consult your hearing care professional Not loud enough • • • • • • Loose earmould Blocked earmould or dome Change in hearing
Troubleshooting Guide SYMPTOM CAUSE Squealing POSSIBLE REMEDY • • • • • • Loose earmould The Dual Stabilizer II system needs re-initialization Dome not placed correctly Build-up of earwax Flex Tube connection loose Instrument settings not optimal • Remove and reinsert • Consult your hearing care professional • • • • Remove and reinsert Consult your physician Flex Tube to be changed Consult your hearing care professional Sound not clear or distorted Weak battery Poorly fitting earmould or do
Key Word Index Advice/Adjusting to the hearing aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Battery change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Battery compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4,17 Cerumen/earwax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Cleaning the instrument . . . . . . . . . . .
