Quick Setup Get the Alula App Power Kit Installation Doorbell Installation Doorbell Setup
Box Contents Mounting Plate (x2) Pick the one for best surveillance angle. Plate Foam (x1) Stabilize the mounting plate when installing it on the rough surface.
Basics Faceplate Lens MIC QR Code Reset Button Doorbell LED Indicator Terminals Micro SD Card Slot (Behind the cover) Speaker Name Description LED Indicator Red • Solid Red: Doorbell is starting up. • Fast-flashing Red: Doorbell exception (e.g. Micro SD card error). Blue • Solid Blue: Doorbell is functioning properly. • Fast-flashing Blue: Doorbell is ready for WiFi connection. Micro SD Card (sold separately) Initialize the card in the Alula app before using it.
Wiring Overview Alula doorbell with chime If you have mechanical chime or electronic chime installed in your home, install the power kit and doorbell, and connect the wires as shown in the figure below.
Power Kit Installation The power kit ensures that your doorbell gets the power it needs, so be sure to install it before you install your Doorbell. 1 Shut off the electricity at the breaker that controls doorbell's circuit. 2 Insert one end of the wire harness into the power kit. 3 Remove the cover from your mechanical chime. 4 Remove the existing chime wires in the terminals named TRANS and FRONT.
5 Connect the wire harness to the chime's terminals named TRANS and FRONT. 6 Insert the existing chime wire and the other end of the wire harness into the wire connector and twist it tightly. Repeat this step with the other chime wire. Wire Connector Chime Wire Wire Harness 7 Mount the power kit to the side of the chime. 8 Put back the chime cover.
Doorbell Installation Recommended Installation Height: 1.2 m (4 ft) above the ground. off the electricity at the breaker that controls doorbell's 1 Shut circuit. When the wall is uneven, paste the plate foam to 2 (Optional) the mounting plate. 3 Using your mounting plate as a template, mark the location of the two mounting holes on your wall, and insert anchors, then fix the mounting plate to the wall. Mounting Screw Anchor Recommended Hole Depth: 25 to 30 mm (1 inch to 1.2 inch).
4 If you have a chime installed, follow Option A; If not, follow Option B. Option A Connect doorbell with your existing doorbell wires. Fixing Screw U-Shaped Wire Power Supply: 12 to 24 VAC Option B Connect the fuse wire with your existing doorbell wire. Fuse Wire Fixing Screw Power Supply: 12 to 24 VAC 5 Install the doorbell to the mounting plate.
6 Insert the security screw into the top of the mounting plate to secure the doorbell. 7 Restore the electricity at the breaker. Doorbell is powered on when its indicator flashes blue quickly. If not, make sure your electricity is off and check the wiring. If yes, proceed to doorbell setup. Doorbell Setup 1 Add your doorbell to Alula app. 1. Remove the faceplate of the doorbell.
2. Log in to your Alula account. 3. In the Cameras tab, tap “+” on the upper-right corner to go to the Scan QR Code interface. 4. Scan the QR code on the device or the cover of this quick start guide when the indicator flashes blue. 5. Follow the wizard to add the doorbell to the Alula app. If you want to change the Wi-Fi which your doorbell has connected to, press and hold the reset button for 5s and repeat this part. 6. Put the faceplate back. 2 Choose the corresponding chime type. 1.
Install the Micro SD Card 1. Remove the cover on the side of the doorbell with the screwdriver. 2. Insert a micro SD card (sold separately) into the slot until a click. 3. Place the cover back on, and tighten the screws with the screwdriver. After installing the micro SD card, you should initialize the card in the Alula app before using it. Initialize Micro SD Card 1. In the Alula app, tap the Storage Settings in the Device Settings interface to check the micro SD card status. 2.
Troubleshooting 1 I have installed my doorbell, but the chime in my home doesn’t function. Please confirm the following details. 1. Make sure the right input voltage range (12V to 24V) has been used. Your doorbell is designed to work with at least 12 volts of AC power, which is in line with a majority of standard doorbell systems. Doorbell running at a lower voltage (or runs on DC rather than AC) may cause chime malfunction. 2. Select the right chime type (same as the product label) in the Alula app. 3.
About this Manual The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
Scan the QR code with the Alula App to add the device to your account Please keep QR Code for further reference.
About this Manual The Manual includes instructions for using and managing the product.Pictures, charts, images and all other information hereinafter are fordescription and explanation only. The information contained in theManual is subject to change, without notice, due to firmware updatesor other reasons.
Regulatory Information FCC Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2)This device must accept any interference received, includinginterference that may cause undesired operation. Note: This product has been tested and found to comply with the limitsfor a Class B digital device, pursuant to Part 15 of the FCC Rules.
afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux. (ii) le gain d'antenne maximal autorisé pour les appareils dans les bandes 5250-5350 MHz doivent respecter le pire limiter; et (iii) le gain d'antenne maximal autorisé pour les appareils dans la bande 5725-5825 MHz doivent respecter le pire limites spécifiées pour le point-à-point et l'exploitation non point à point, le cas échéant.
